Specifications

Primary Voltage 1 ph

230 VAC +/- 10%,  50/60 Hz

Primary Voltage 3 ph

230-480 VAC +/- 10%,  50/60 Hz

Fuse Slow

16 A at 400 V

Energy Save Mode

88 W at 400 V

Maximum Output

300 A

Power Factor at Max Current

0.96

Efficiency at Max Current TIG / MMA

88 % / 84 %

Open Circuit Voltage with / without VRD

33 V / 48 V

TIG Welding Output

40% Duty Cycle

60% Duty Cycle

100% Duty Cycle

300 A / 22.0 V

250 A / 20.0 V

200 A / 18.0 V

MMA Welding Output

40% Duty Cycle

60% Duty Cycle

100% Duty Cycle

300 A / 32.0 V

250 A / 30.0 V

200 A / 28.0 V

Current Range

5 – 300 A (TIG and MMA)

Approvals

CE

Protection Class

IP23

Mains Cable

3 m, 4×2,5 mm² (4×4 mm² with 230 V)

Supply Plug

CEE 16 A

Dimensions, Lx W x H

460 x 200 x 320 mm

Weight without / with Cooler

16.9 kg / 26.9 kg
